This magnet wire is engineered for the rigorous demands of electric motors, transformers, relays, and other high-speed winding applications. Its superior flexibility allows it to be easily formed into precise coils that maintain their shape permanently, ensuring consistent performance and reliable operation.
Key Features & Specifications:Comprehensive Size Range: Available in a versatile selection of diameters from 0.315mm to 1.4mm to meet diverse design and power requirements.
Exceptional Thermal Endurance: With a maximum operating temperature of 390° F (199° C), this wire is built to withstand the heat generated in high-performance electrical equipment.
Durable Polyamide Insulation: The wire is coated with a tough yet flexible polyamide layer. This insulation provides excellent dielectric strength, resistance to mechanical stress, and protection against harsh environmental factors.
Proven Material Quality: This magnet wire is manufactured to meet the exacting standards of NEMA MW-35C, guaranteeing material consistency and performance reliability. It is also rated for use in sealed motor applications at temperatures as low as -73° C, ensuring integrity across a wide thermal range.
| DESCRIPTION |
SPEC |
MATERIAL CLASS |
QTY |
| WINDING WIRE |
0.315MM |
Class H, enameled |
30kg |
| WINDING WIRE |
0.90MM |
Class H, enameled |
50kg |
| WINDING WIRE |
0.95MM |
Class H, enameled |
100kg |
| WINDING WIRE |
1.0MM |
Class H, enameled |
100kg |
| WINDING WIRE |
1.06MM |
Class H, enameled |
100kg |
| WINDING WIRE |
1.12MM |
Class H, enameled |
100kg |
| WINDING WIRE |
1.18MM |
Class H, enameled |
100kg |
| WINDING WIRE |
1.25MM |
Class H, enameled |
100kg |
| WINDING WIRE |
1.32MM |
Class H, enameled |
100kg |
| WINDING WIRE |
1.40MM |
Class H, enameled |
150kg |
